Titan-X

Engineered to handle your toughest lifting challenges with ease.

The Next Generation Davit Crane

Seasight Davits proudly presents the Titan-X, the latest evolution in our renowned line of davit cranes. Developed in response to growing demand for greater lifting capacity and extended outreach, the Titan-X sets new standards in performance and reliability.

With an outreach available from 4.5 to 8 meters, the Titan-X is tailored to your specifications. It boasts exceptional lifting power, capable of handling 3000 kg at a 7-meter outreach and 2000 kg at an 8-meter outreach. Equipped with electrical slewing for smooth and precise movements, the Titan-X is built on the trusted design of our original Titan crane, ensuring familiarity and reliability.

Its durable construction features a closed crane house for enhanced protection and longevity, and the Plug and Play setup allows for quick and effortless installation. Experience the superior functionality and practical design of the Titan-X.

1 General information
1.1	Crane model	Titan-X
1.2	Crane type	Fixed boom crane model
1.3	Design life (year)	35 years operation + 2 years during installation phase
1.4	Service interval	12 months +/- 1 month
1.5	Approvals/Standards	EU Declaration of Conformity (CE marked) Machinery Directive 2006/42/EC Electromagnetic Compatibility (EMC) directive 2014/30/EU Low voltage Directive 2014/35/euSurface protection: Corrositivity category CX (offshore) according to EN12944-9:2018 Paints and varnishes EN13852-3: Light offshore cranes EN1461:2022

1 General information

1.1

Crane model

Titan-X

1.2

Crane type

Fixed boom crane model

1.3

Design life (year)

35 years operation + 2 years during installation phase

1.4

Service interval

12 months +/- 1 month

1.5

Approvals/Standards

EU Declaration of Conformity (CE marked)
Machinery Directive 2006/42/EC
Electromagnetic Compatibility (EMC) directive 2014/30/EU
Low voltage Directive 2014/35/euSurface protection:
Corrositivity category CX (offshore) according to
EN12944-9:2018
Paints and varnishes
EN13852-3: Light offshore cranes
EN1461:2022

2 Crane main dimensions
2.1	Outreach	Min: 4.500 mm	Max: 8.000 mm
2.2	Hook height above crane base	6000 mm
2.3	Hoisting height (horizontal hook to LAT)	Max: 35 meters
2.4	Pivot bar height (operation)	1800 - 2000 mm in relation to interface height
2.5	Total crane weight	Min: 2.200 kg	Max: 4.000 kg

2 Crane main dimensions

2.1

Outreach

Min: 4.500 mm

Max: 8.000 mm

2.2

Hook height above crane base

6000 mm

2.3

Hoisting height (horizontal hook to LAT)

Max: 35 meters

2.4

Pivot bar height (operation)

1800 - 2000 mm in relation to interface height

2.5

Total crane weight

Min: 2.200 kg

Max: 4.000 kg

3 Technical specification
3.1	Max rated capacity (SWL) 4,5-7m outeach	Min: 1.000 kg	Max: 3.000 kg
3.2	Max rated capacity (SWL) 7-8m outeach	Electrical
3.3	Hoisting type	Speed 1: 10 m/min	Speed 2: 40 - 20 m/min
3.4	Hoisting speed	Manual or Electrical
3.5	Slewing type	Electrical
3.6	Slewing angle	355° with adjustable slewing stops
3.7	Slewing speed	Electrical:	Adjustable up to 1 rev/min
3.8	Electrical slewing stop	2 end-stops
3.9	Hook on point	SWL 30 kN and painted red (RAL 3020)
3.10	Rescue point	SWL 30 kN and painted yellow (RAL 1003)
3.11	Anchor point	SWL 20 kN placed on pedestal according to EN50308
3.12	Centrifugal brake	Yes

3 Technical specification

3.1

Max rated capacity (SWL) 4,5-7m outeach

Min: 1.000 kg

Max: 3.000 kg

3.2

Max rated capacity (SWL) 7-8m outeach

Electrical

3.3

Hoisting type

Speed 1: 10 m/min

Speed 2: 40 - 20 m/min

3.4

Hoisting speed

Manual or Electrical

3.5

Slewing type

Electrical

3.6

Slewing angle

355° with adjustable slewing stops

3.7

Slewing speed

Electrical:

Adjustable up to 1 rev/min

3.8

Electrical slewing stop

2 end-stops

3.9

Hook on point

SWL 30 kN and painted red (RAL 3020)

3.10

Rescue point

SWL 30 kN and painted yellow (RAL 1003)

3.11

Anchor point

SWL 20 kN placed on pedestal according to EN50308

3.12

Centrifugal brake

Yes

4 Electrical
4.1	Main power supply	3x400VAC + N 50/60 Hz.
4.2	Power consumption (full load)	Approx. 8-18 kW depending on SWL
4.3	Protection	Depending on SWL
4.4	Service form	S3-15% ED
4.5	Earth connection	Earth stud on crane pedestal
4.6	Remote control	Wired remote control as standard
4.7	Acoustic alarm	110 dB alarm
4.8	Emergency stops	2x (One on portable remote control and one on crane house)
4.9	Ingress protection	Remote control: IP66Control box: IP65Emergency stop: IP66Electrical motor: IP66Motor brake: IP55Cam switch: IP66
4.10	Supply cable length	23 meters as standard (additional as option)

4 Electrical

4.1

Main power supply

3x400VAC + N 50/60 Hz.

4.2

Power consumption (full load)

Approx. 8-18 kW depending on SWL

4.3

Protection

Depending on SWL

4.4

Service form

S3-15% ED

4.5

Earth connection

Earth stud on crane pedestal

4.6

Remote control

Wired remote control as standard

4.7

Acoustic alarm

110 dB alarm

4.8

Emergency stops

2x (One on portable remote control and one on crane house)

4.9

Ingress protection

Remote control: IP66Control box: IP65Emergency stop: IP66Electrical motor: IP66Motor brake: IP55Cam switch: IP66

4.10

Supply cable length

23 meters as standard (additional as option)

5 Environments
5.1	max/min ambient temperature	Min: -20°C	Max: +45°C
5.2	Max Wind velocity (gust)	Operation: 15 m/sec	Stored: 63 m/sec
5.3	Max wave height (Hs)	Operation: Up to 2.0 meters (depending on WLL)

5 Environments

5.1

max/min ambient temperature

Min: -20°C

Max: +45°C

5.2

Max Wind velocity (gust)

Operation: 15 m/sec

Stored: 63 m/sec

5.3

Max wave height (Hs)

Operation: Up to 2.0 meters (depending on WLL)

6 Corrosion protection
6.1	Standard reference	EN12944-9
6.2	Coating system	Inside: C3	Outside: CX
6.3	Main color	RAL 7035
6.4	Galvanised items	All structured steel components

6 Corrosion protection

6.1

Standard reference

EN12944-9

6.2

Coating system

Inside: C3

Outside: CX

6.3

Main color

RAL 7035

6.4

Galvanised items

All structured steel components

7 Additional options
7.1	Wireless remote	As option
7.2	Stepdown transformer	As option
7.3	OVP box	As option
7.4	Alarm monitoring	As option
7.5	CEE power inlet	As option
7.6	Operation light	As option

7 Additional options

7.1

Wireless remote

As option

7.2

Stepdown transformer

As option

7.3

OVP box

As option

7.4

Alarm monitoring

As option

7.5

CEE power inlet

As option

7.6

Operation light

As option

Seasight Davits makes
customized standard

As Seasight Davits handles the design, engineering, and product development in-house, we always have the opportunity of customizing our davit cranes and lifting solutions to meet all customer requirements and specifications. Additionally, we have a wide range of optional upgrades and retrofit solutions. And we are always happy to examine and evaluate further solutions with our customers.
